22.2. GSM/GPrS antenna Status Monitoring

the system constantly monitors the GSM/GPRS antenna status. If the GSM/GPRS antenna is disconnected/cut-off, the system may send
notification by SMS text message (by default - disabled) to the listed user and the keypad will indicate system fault condition (see 29. In-
DICatIon of SYStEM faUltS). Once the antenna is connected/fixed, the system may notify the user by SMS text message (by default
- disabled) and the keypad will no longer indicate system fault.
By default, the notification by SMS text message regarding the GSM/GPRS antenna status is disabled. to enable/disable this notification,
please refer to the following configuration methods.
Enable GSM/GPrS
antenna fail/restore
notification
Disable GSM/GPrS
antenna fail/restore
notification
For more details on how Send SMS text message to all users simultaneously and SMS Cascade parameters affect the SMS text message
transmission, please refer to 27. SYStEM notIfICatIonS.
110 110 EN
Menu path:
User phone number:
EKB2
GSM USeR 1... 10 → OK → eNABLe → OK
SMS text message to all users simultaneously:
→ OK → eNABLe → OK
SMS delivery report:
Value: iiii – 4-digit installer code.
Enter parameter 25/21/55, event number, user phone number slot and parameter
EKB3/
status value:
EKB3W/
User phone number:
EWKB4
SMS text message to all users simultaneously:
SMS delivery report:
Value: up - user phone number slot, range - [01... 10].
Example: 2512031#
ElDES
Config-
this operation may be carried out from the PC using the ELDES Configuration software.
uration
software
Menu path:
User phone number:
EKB2
GSM USeR 1... 10 → OK → DISABLe → OK
SMS text message to all users simultaneously:
→ OK → DISABLe → OK
SMS delivery report:
Value: iiii – 4-digit installer code.
Enter parameter 25/21/55, event number, user phone number slot and parameter
EKB3/
status value:
EKB3W/
User phone number:
EWKB4
SMS text message to all users simultaneously:
SMS delivery report:
Value: up - user phone number slot, range - [01... 10].
Example: 2512030#
ElDES
Config-
this operation may be carried out from the PC using the ELDES Configuration software.
uration
software
OK → iiii → OK → SMS MeSSAGeS 2 → OK → GSM ANt FAIL/ReSt → OK →
... → GSM ANt FAIL/ReSt → OK → SMS tO ALL
... → GSM ANt FAIL/ReSt → OK → SMS RePORt → OK → eNABLe → OK
25 12 up 1 #
21 12 1 #
55 12 1 #
OK → iiii → OK → SMS MeSSAGeS 2 → OK → GSM ANt FAIL/ReSt → OK →
... → GSM ANt FAIL/ReSt → OK → SMS tO ALL
... → GSM ANt FAIL/ReSt → OK → SMS RePORt → OK → DISABLe → OK
25 12 up 0 #
21 120 #
55 120 #
