Eldes ESIM264 Installation Manual

Gsm alarm and management system
Hide thumbs Also See for ESIM264:
Table of Contents

Advertisement

Quick Links

Download this manual
ESIM264
GSM ALARM AND MANAGEMENT SYSTEM
INSTALLATION MANUAL
COMPLIES WITH EN 50131-1 GRADE 2, CLASS II REQUIREMENTS

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ESIM264 and is the answer not in the manual?

Questions and answers

Related Manuals for Eldes ESIM264

Summary of Contents for Eldes ESIM264

  • Page 1 ESIM264 GSM ALARM AND MANAGEMENT SYSTEM INSTALLATION MANUAL COMPLIES WITH EN 50131-1 GRADE 2, CLASS II REQUIREMENTS...

  • Page 2: Table Of Contents

    • System label is on the bottom side of the device. CONFIGURATION METHODS ..............................23 GSM alarm system ESIM264 is a device mounted in limited access areas. Any system repairs must be done only by qualified, 5.1. SMS Text Messages ......................................23 safety aware personnel.
  • Page 3 19.3. Wireless Signal Status Monitoring ................................64 “ELDES UAB” liability according to local laws does not exceed value of the purchased system. “ELDES UAB” is not affiliated with any of the 19.4. Disabling and Enabling Siren if Wireless Signal is Lost ..........................64 cellular providers therefore is not responsible for the quality of cellular service.

  • Page 4: General Information

    Parameter Default Value Configuration ** - Only 1 of these modules can be connected at a time if the module slots are implemented in ESIM264 unit. SMS EKB2 EKB3 Tool *** - A mixed combination of wireless devices is supported. The combination can consist of up to 16 wireless devices in total.
  • Page 5 User Code 1... 30 Partition PART0    User 1... 5 Phone Number Partition PART0    iButton 1... 5 Partition PART0    Zone Partition PART0    MANUAL ELDES ESIM264 V3.2 MANUAL ELDES ESIM264 V3.2...

  • Page 6: Technical Specifications

    Siren positive terminal AUX- Negative power supply terminal for auxiliary equipment AUX+ Positive power supply terminal for auxiliary equipment AC/DC Mains power terminal AKU- Backup battery negative terminal AKU+ Backup battery positive terminal MANUAL ELDES ESIM264 V3.2 MANUAL ELDES ESIM264 V3.2...

  • Page 7: Wiring Diagrams

    Based on the example given, in the event of an alarm, the smoke detector could be reset by turning OFF and ON the PGM output C1. For more details, please refer to 18.4. Turning PGM Outputs ON and OFF. NOTE: The system does NOT support 2-wire smoke detectors. MANUAL ELDES ESIM264 V3.2 MANUAL ELDES ESIM264 V3.2...
  • Page 8 1 Wire up relay A1 terminal to PGM output Cx and A2 terminal to AUX+. 2 In addition, connect the switching diode to re- lay‘s A2 and A1 terminals. COIL RELAY NOTE: We highly recommend using switching diode model 1N4148 or similar. MANUAL ELDES ESIM264 V3.2 MANUAL ELDES ESIM264 V3.2...

  • Page 9: Ekb2 Ekb3

    If necessary, the RS485 devices can be powered from an external 12-14V DC power supply instead of AUX+ and AUX- terminals RELAY ATTENTION: The cable between ESIM264 and each RS485 device must be of the same length and can NOT exceed 100m (328.08ft). NOTE: We highly recommend using switching diode model 1N4148 or similar.

  • Page 10: Installation

    Phase 3. If EPGM1 module is to be installed, please install it in the first place and ESIM264 alarm system afterwards. EPGM1 must be mounted on Fuse 1A the shorter plastic standoffs, while ESIM264 – on the longer ones. The mounting points of EPGM1 module are indicated below.
  • Page 11 SMS text message delivery service and phone call connection. NOTE: Even though alarm system ESIM264 installation process is not too complicated, we still recommend to perform it by a person with basic knowledge in electrical engineering and electronics to avoid any system damage.

  • Page 12: General Operational Description

    Force attribute enabled. In order to configure and control the system by SMS text message, send the text command to the ESIM264 system phone After the system is armed and if a zone (depending on type) or tamper is violated, the system will cause an alarm lasting for 1 minute (by number from one of the listed user phone numbers.

  • Page 13: Passwords

    In order to start using the remote configuration feature, please run the step-by-step wizard and follow the steps provided in the start page of ELDES Configuration Tool software. Please, note that it will be necessary to send an SMS text message to the system’s phone number in order to initiate the remote connection.

  • Page 14: System Language

    The system supports up to 5 user phone numbers identified as User 1 through 5. When the phone number is set, the user will be able to keypad menu display. The default EKB2 menu language depends on ESIM264 firmware, which is based on the user’s location, while one of arm/disarm the system by SMS text messages and free of charge phone calls (see 12.1.

  • Page 15: System Control From Any Phone Number

    SETTINGS → OK → CTRL FROM ANY NUM → OK → ENABLE → OK Config Value: aaaa – 4-digit administrator password. This operation may be carried out from the PC using the ELDES Configuration Tool software. Tool Enter parameter 12 and parameter status value:...

  • Page 16: User Codes

    Value: aaaa – 4-digit administrator password; uuuu – 4-digit user code, range – [0000... 9999]. Config This operation may be carried out from the PC using the ELDES Configuration Tool software. Enter parameter 15, user code slot and user code: Tool...

  • Page 17: Ibutton Keys

    An iButton key is a unique 64-bit ID code containing chip enclosed in a stainless steel tab usually implemented in a small plastic holder. Disable Allow Adding ssss_IBPROG:OFF ESIM264 system supports up to 5 iButton keys each holding a unique identity code (ID), which is used for system arming and disarming. New iButton Keys Value: ssss – 4-digit SMS password.

  • Page 18: Arming And Disarming

    By default when a valid user code is entered, the system will initiate exit delay, the keypad’s buzzer will emit short beeps and the keypad will display icon next to the countdown timer. When the system is successfully armed, the keypad will display icon for 5 seconds and switch to home screen view. MANUAL ELDES ESIM264 V3.2 MANUAL ELDES ESIM264 V3.2...

  • Page 19: Ekb3 Keypad And User Code

    The system will arm/disarm the partition corresponding to the one that user code and the key pad are assigned to. For example, if EKB3 keypad and user code is assigned to Partition 0, the user will be able to arm/ disarm only Partition 0. For more details on how to set user MANUAL ELDES ESIM264 V3.2 MANUAL ELDES ESIM264 V3.2...
  • Page 20 DISABLE → OK another EWK1/EWK2 keyfob with the system and assign it to a different partition. number For more details on how to manage EWK1/EWK2 keyfob buttons, please refer to ELDES Configuration Tool software‘s HELP Value: aaaa – 4-digit administrator password. section.

  • Page 21: Exit And Entry Delay

    Example: 220# Exit delay is provided when arming the system by the following methods: Config This operation may be carried out from the PC using the ELDES Configuration Tool software. • EKB2/EKB3 keypad and user code. Tool •...

  • Page 22: Zones

    14.3. 6-Zone Mode By default, ESIM264 alarm system runs in the 6-Zone mode under zone connection Type 1 allowing to connect up to 6 detection devices of NO (normally-open) type to the on-board zone terminals as indicated in the wiring diagram of Type 1. Once a different zone connection type is set, the detection device wiring must be done according to the wiring diagram of the associated type.

  • Page 23: Atz (Advanced Technology Zone) Mode

    – Type 2 39 3 # – Type 3 Config This operation may be carried out from the PC using the ELDES Configuration Tool software. Example: 392# Tool Config This operation may be carried out from the PC using the ELDES Configuration Tool software.

  • Page 24: Zone Type Definitions

    Example: 53125# Value: aaaa – 4-digit administrator password. Config Enter parameter 56, zone number and parameter status value: This operation may be carried out from the PC using the ELDES Configuration Tool software. Tool 56 nn 0 # EKB3 Value: nn – zone number, range – [01... 44].

  • Page 25: Bypassing And Activating Zones

    Config EKB2 Bypass all violated Set Delay, ms atrribute This operation may be carried out from the PC using the ELDES Configuration Tool software. Menu path: Tool zones OK → BYPASS → OK → BYP VIOLATED ZONES → OK The zone will stay bypassed until the system is disarmed. Once the system is disarmed, the corresponding zone state will be indicated on the keypads (see 31.1.1.

  • Page 26: Disabling And Enabling Zones

    System arming in Stay mode by the keypad must be carried out without Configuration mode being activated. Config This operation may be carried out from the PC using the ELDES Configuration Tool software. NOTE: The system can be armed in Stay mode, only if there is at least one zone with Stay attribute enabled.

  • Page 27: Tampers

    Config This operation may be carried out from the PC using the ELDES Configuration Tool software. a) If the user phone number is unavailable and the system fails to receive the SMS delivery report during 45 seconds, it will attempt to Tool send the SMS text message to the next listed user phone number, assigned to the same partition as the previous one.

  • Page 28: Enabling And Disabling Alarm Notifications

    SYSTEM stands for violated high-numbered zones (Z13-Z44). For more Config EKB3 This operation may be carried out from the PC using the ELDES Configuration Tool software. details on violated high-numbered zone indication, please refer to 29. INDICATION OF SYS- Tool TEM FAULTS.

  • Page 29: Programmable (Pgm) Outputs

    This operation may be carried out from the PC using the ELDES Configuration Tool software. Tool ESIM264 comes equipped with four open-collector PGM outputs allowing to connect up to four devices or relays. For more details on PGM output expanding, please refer to 18.2. PGM Output Expansion.
  • Page 30 → DISABLE → OK Example: 61031# Value: aaaa – 4-digit administrator password. Config Enter parameter 33 and parameter status value: This operation may be carried out from the PC using the ELDES Configuration Tool software. EKB3 33 0 # Tool Example: 330#...

  • Page 31: Wireless Pgm Output Type Definitions

    • Turn OFF – Determines whether the PGM output is to be turned OFF. individual wireless This operation may be carried out from the PC using the ELDES Configuration Tool software. Tool • Pulse – Determines whether the PGM output is to be turned ON for a set period of time in seconds.

  • Page 32: Wireless Devices

    Example: 1111_REP:535185D<41286652 Once the wireless device is paired, it will attempt to exchange data with ESIM264 system. Due to battery saving reasons, all ELDES wireless devices operate in sleep mode. The data exchange will occur instantly if the wireless device is triggered (zone alarm or tamper alarm) or When a wireless device is successfully replaced with a new one, the configuration of the old wireless device remains.

  • Page 33: Wireless Signal Status Monitoring

    This operation may be carried out from the PC using the ELDES Configuration Tool software. Tool EWT1 enables ESIM264 alarm system to connect up to 16 wireless devices at a time. Maximum wireless connection range is 150m (492.13ft) (in open areas).

  • Page 34: Ewf1 - Wireless Smoke Detector

    19.6. EWF1 - Wireless Smoke Detector Config This operation may be carried out from the PC using the ELDES Configuration Tool software. Main features: Tool • Photoelectric sensor for slow smouldering fires • TEST button • Non-radioactive technology for environmental friendly...

  • Page 35: Wired Siren/Bell

    Enter parameter 10 and alarm duration: Config 10 tt # EKB3 This operation may be carried out from the PC using the ELDES Configuration Tool software. Tool Value: tt – alarm duration, range – [00... 10] minutes. Example: 1007# Menu path: Config This operation may be carried out from the PC using the ELDES Configuration Tool software.

  • Page 36: Indication By Ews3 - Wireless Indoor Siren Indicators

    21. BACKUP BATTERY, MAINS POWER STATUS MONITORING AND MEMORY Config This operation may be carried out from the PC using the ELDES Configuration Tool software. 21.1. Backup Battery Status Monitoring Tool The system may come equipped with a backup battery maintaining power supply of the system when the mains power supply is temporally lost.

  • Page 37: Mains Power Status Monitoring

    Enter parameter 25, notification number and parameter status value: Config 25 061 # EKB3 This operation may be carried out from the PC using the ELDES Configuration Tool software. Tool Example: 25061# Config This operation may be carried out from the PC using the ELDES Configuration Tool software.

  • Page 38: Gsm Connection Status Monitoring

    Value: aaaa – 4-digit administrator password; ESIM264 system comes equipped with a partitioning feature that can divide the alarm system into two independently controlled areas identified as Partition 0 through 1, which are all supervised by one alarm system unit. Partitioning can be used in installations where shared Enter parameter 51, keypad slot and partition number: alarm system is more practical, such as a house and a garage or within a single multi-storey building.

  • Page 39: Ibutton Key Partition

    24. TEMPERATURE SENSOR Config This operation may be carried out from the PC using the ELDES Configuration Tool software. Tool The system may be equipped with a temperature sensor intended for temperature measurement in the surrounding area. This feature allows to monitor the temperature in real-time and receive a notification by SMS text message to the listed user phone number when the set temperature boundaries are exceeded.

  • Page 40: Remote Listening And 2-Way Voice Communication

    MAX temperature Value: ssss – 4-digit SMS password. ESIM264 comes equipped with a microphone that allows the user to listen on his mobile phone to what is happening in the secured area. boundaries By installing one of the audio module EA2, the user will be able to have a 2-way voice communication (see 31.3.2. EA2 – Audio Output Example: 1111_TEMP Module with Amplifier).

  • Page 41: System Information. Info Sms

    Info SMS that provides the following: • System date and time. Config • System status: partition armed (ON)/disarmed (OFF). This operation may be carried out from the PC using the ELDES Configuration Tool software. Tool • GSM signal strength. • Mains power supply status.

  • Page 42: System Notifications

    Config Periodical info Info SMS text message sent to the user periodically by the set values. This operation may be carried out from the PC using the ELDES Configuration Tool software. Tool Tamper alarm SMS text message sent to the user in case of tamper violation. Indicated as Tamper x.

  • Page 43: Smsc (Short Message Service Center) Phone Number

    Value: uuuu - 4-digit user code. Config This operation may be carried out from the PC using the ELDES Configuration Tool software. Tool To export the event log to .log file or clear it, please refer to the following configuration method.

  • Page 44: Indication Of System Faults

    One or more high-numbered zones are violated Config This operation may be carried out from the PC using the ELDES Configuration Tool software. Tool In order to find out more on the particular system fault, please enter command A provided below. After this procedure the system will activate red zone LEDs for 15 seconds.

  • Page 45: Data Messages - Events

    3602 Test event/Kronos ping Transmitted for system online status verification purposes. 3626 Date/time not set Transmitted in case system date and time is not set. 1900 System started Transmitted on system startup. MANUAL ELDES ESIM264 V3.2 MANUAL ELDES ESIM264 V3.2...
  • Page 46 – System shutdown Example: 24031# Example: 24080# Config This operation may be carried out from the PC using the ELDES Configuration Tool software. Config Tool This operation may be carried out from the PC using the ELDES Configuration Tool software.

  • Page 47: Communication

    Transmits all queued up data Delay after last communication attempt Returns to PRIMARY Returns to PRIMARY NOTE: The number of attempts, indicated in the diagram, are default and depends on the determined communication method. MANUAL ELDES ESIM264 V3.2 MANUAL ELDES ESIM264 V3.2...
  • Page 48 The system is fully compatible with Kronos NET/Kronos LT monitoring station software for communication via GPRS network. When 48 2 # – RS485 using a different monitoring station software, EGR100 middleware is required. EGR100 is freeware and can be downloaded at www.eldes.lt/ 48 3 # – CSD en/download.
  • Page 49 EKB3 Config 43 1 # - UDP This operation may be carried out from the PC using the ELDES Configuration Tool software. Tool Config This operation may be carried out from the PC using the ELDES Configuration Tool software. Tool...
  • Page 50 0 value disables test period. Config This operation may be carried out from the PC using the ELDES Configuration Tool software. Tool Unit ID is a 4-digit number (By default – 0000) required to identify the alarm system unit by ESR100 digital receiver or EGR100 middle-ware.
  • Page 51 Value: aaaa – 4-digit administrator password. ing station phone number. Example: 85014417091111111# Config This operation may be carried out from the PC using the ELDES Configuration Tool software. Tool Config This operation may be carried out from the PC using the ELDES Configuration Tool software.

  • Page 52: Wired Devices

    GARAGE For more details on RS485 device wiring, please refer to 3.2.7. RS485. message For more details on technical specifications and installation, please refer to the latest user manual of the device located at www.eldes.lt/ download One or more One or...
  • Page 53 PARTITION PARTITION0 | PARTITION1 N/A | 1... 10 DURESS PASSWORD FORCE DISABLE | ENABLE SGS PASSWORD N/A | 1... 10 [0000... 9999] REMOVE PASSWORD Continued in next page Continued in next page MANUAL ELDES ESIM264 V3.2 MANUAL ELDES ESIM264 V3.2...
  • Page 54 TEL. NUMBER3 ttteeellnnuumm 15 digits BACKUP CONNECTION4 TCP | UDP PROTOCOL PASSWORD GPRS | VOICE CALLS | RS485 | CSD | SMS | N/A [1... 65535] SERVER PORT PROFILE Continued in next page MANUAL ELDES ESIM264 V3.2 MANUAL ELDES ESIM264 V3.2...

  • Page 55: 1-Wire Interface

    • Keypad partition switch (see 23.3. Keypad Partition and Keypad Partition Switch). • 3,5 mm female jack For more details on technical specifications and installation, please refer to the latest user manual of the device located at www.eldes.lt/ • Dimensions: 41x40x24mm (1.61x1.57x0.95in) download 31.3.1.2.

  • Page 56: Remote System Restart

    31.3.2. EA2 – Audio Output Module with Amplifier In some critical situations, a system restart may be required. To remotely carry out system restart, please refer to the following configu- EA2 audio output module enables a duplex audio connection for ESIM264 alarm system. ration method.

  • Page 57: Technical Support

    If your problem could not be fixed by the self-guide above, please contact your local distributor. More up to date information about your device ATTENTION: “ELDES UAB” does not run a FTP server and does not host the firmware files online. Please, contact your local distributor to and other products can be found at the manufacturer’s website www.eldes.lt request the latest firmware file.

  • Page 58: Related Products

    10. I connect the wired siren to ESIM264 and I hear a silent sound alarm even when the alarm system is disarmed. Please, connect the resistor of 3,3 kΩ nominal to the BELL- / BELL+ contacts In case of alarm system alarm the siren provides a loud This should solve the problem.
  • Page 59 3m (9.84ft) wire and temperature sensor ESR100 - digital receiver EWS2 - wireless external siren EWF1 – wireless smoke detector EWK1 - wireless keyfob EW2 - wireless zone and PGM output expansion module MANUAL ELDES ESIM264 V3.2 MANUAL ELDES ESIM264 V3.2...
