22. GSM ConnECtIon anD antEnna StatUS MonItorInG

22.1. GSM Connection Status Monitoring

the system supervises the GSM connection every 10 minutes. When the GSM connection loss is detected, the system indicator NetW will
light OFF and the system will attempt to restore the GSM connection. In case the system fails to restore the GSM connection within a 3-min-
ute period (by default), the keypad will indicate the system fault condition (see 29. InDICatIon of SYStEM faUltS) and the system will
continue the attempt to restore the GSM connection. In addition, the system may turn ON a determined PGM output to indicate the GSM
connection loss fault (by default - disabled).
Once the GSM signal restores, the system may notify the listed user by SMS text message (by default - disabled), the keypad will no longer
indicate system fault and the determined PGM output will turn OFF (if set up).
By default, the notifications by SMS text message regarding GSM signal loss is disabled. to enable/disable this notification, please refer to
the following configuration methods.
Enable GSM
Connection failed
notification
Disable GSM
Connection failed
notification
By default, the PGM output for GSM signal loss indication is not set. to set the PGM output and delay duration for GSM signal loss indication,
please refer to the following configuration method.
Manage GSM signal
loss indication by PGM
output
For more details on how Send SMS text message to all users simultaneously and SMS Cascade parameters affect the SMS text massage
transmission, please refer to 27. SYStEM notIfICatIonS.
ESIM384 Installation and Configuration Manual v1.1
Menu path:
User phone number:
EKB2
→ GSM USeR 1... 10 → OK → eNABLe → OK
SMS text message to all users simultaneously:
ALL → OK → eNABLe → OK
SMS delivery report:
Value: iiii – 4-digit installer code.
Enter parameter 25/21/55, event number, user phone number slot and parameter
EKB3/
status value:
EKB3W/
User phone number:
EWKB4
SMS text message to all users simultaneously:
SMS delivery report:
Value: up - user phone number slot, range - [01... 10].
Example: 21111#
ElDES
Config-
this operation may be carried out from the PC using the ELDES Configuration software.
uration
software
Menu path:
User phone number:
EKB2
→ GSM USeR 1... 10 → OK → DISABLe → OK
SMS text message to all users simultaneously:
ALL → OK → DISABLe → OK
SMS delivery report:
Value: iiii – 4-digit installer code.
Enter parameter 25/21/55, event number, user phone number slot and parameter
EKB3/
status value:
EKB3W/
User phone number:
EWKB4
SMS text message to all users simultaneously:
SMS delivery report:
Value: up - user phone number slot, range - [01... 10].
Example: 2511020#
ElDES
Config-
this operation may be carried out from the PC using the ELDES Configuration software.
uration
software
ElDES
Config-
this operation may be carried out from the PC using the ELDES Configuration software.
uration
software
OK → iiii → OK → SMS MeSSAGeS 2 → OK → GSM CONNeCt FAILeD → OK
... → GSM CONNeCt FAILeD → OK → SMS tO
... → GSM CONNeCt FAILeD → OK → SMS RePORt → OK → eNABLe → OK
25 11 up 1 #
21 11 1 #
55 11 1 #
OK → iiii → OK → SMS MeSSAGeS 2 → OK → GSM CONNeCt FAILeD → OK
... → GSM CONNeCt FAILeD → OK → SMS tO
... → GSM CONNeCt FAILeD → OK → SMS RePORt → OK → DISABLe → OK
25 11 up 0 #
21 11 0 #
55 11 0 #
