reset power
consumption counter
for individual EWM1
device
reset power
consumption counter
for all EWM1 devices
simultaneously
notE: Real-time power consumption value is NOt included in the power consumption report requested by SMS text message and can only
be seen on eldes Cloud.

19.10. EWKB5 Wireless touchpad overview

eWKB5 is a wireless accessory equipped with a 4.3" true-colour touch screen and compatible with eSIM384 alarm system.
device features:
• Arming and disarming
• Violated zone bypass and bypassed zone activation
• PGM output control
• Customizable user-friendly graphical menu
• Navigation through the menu using the touch screen
eWKB5 has 1 built-in zone terminal, which is by default designed for passive wired digital sensor connection, such as magnetic door con-
tact, and 2 tamper switches for enclosure state supervision in case it is illegally opened or detached from the wall. Regardless if the tamper
switch alone is to be used, the zone must be enabled and the resistor of 5,6kΩ nominal must be connected across Z1 and COM connectors.
It is possible to connect up to 4 eWKB5 devices to the alarm system eSIM384. the maximum wireless connection range is 1000m (~984ft)
(in open areas).
Main menu features:
Partition button – arms/disarms the system once a valid master/user code PIN is entered; indicates partition status (armed/disarmed),
presence of system faults.
Quick arm button – arms the system by touching and holding this button; master/user code not required (customizable, hidden by default;
not shown in picture).
Bypass - the Bypass icon will be shown on the main screen if any bypassed zone is present.
Fire – instantly causes fire alarm by pressing and holding this button (customizable, hidden by default).
Panic – instantly causes silent alarm by pressing and holding this button (customizable, hidden by default).
Controls – opens PGM output menu, thus letting you turn a certain PGM output ON or OFF (customizable, hidden by default).
Settings – grants access to settings menu once a valid master code is entered.
ESIM384 Installation and Configuration Manual v1.1
Menu path:
Real-time power consumption:
EKB2
OK → ReAL tIMe eNeRGY
today's power consumption:
Monthly power consumption:
Value: mmmm – 4-digit master code; out-name - PGM output name associated with a
certain eWM1 device.
ElDES
Config-
uration
this operation may be carried out from the PC using the ELDES Configuration software.
soft-
ware
SMS text message content:
ssss_eWM1ReSet:out-name
SMS
Value: ssss - 4-digit SMS password; out-name - PGM output name associated with a certain
eWM1 device.
Example: 1111_EWM1RESET:Controll14
Menu path:
OK → mmmm → OK → PGM OUtPUtS → OK → out-name → OK → ReSet COUNteR → OK →
EKB2
YeS → OK
Value: mmmm – 4-digit master code; out-name - PGM output name associated with a
certain eWM1 device.
ElDES
Config-
this operation may be carried out from the PC using the ELDES Configuration software.
uration
software
SMS text message content:
SMS
ssss_eWM1ReSet:ALL
Value: ssss - 4-digit SMS password.
Example: 1111_EWM1RESET:ALL
OK → mmmm → OK → PGM OUtPUtS → OK → out-name →
... → out-name→ OK → tODAY eNeRGY
... → out-name → OK → MONtHLY eNeRGY
• Multilingual voice-guided audio instructions
• Adjustable brightness and volume level
• Battery or externally-powered
• Add/delete/edit username and user/master code PIN (accessi-
ble from the User's menu)
