Eldes ESIM384 Installation Manual page 75

turn on PGM output/
Set PGM output start-
up state as on
turn off PGM output/
Set PGM output start-
up state as off
to instantly turn ON an individual PGM output for a determined time period and automatically turn it OFF when the time period expires,
please refer to the following configuration method.
turn on PGM output
for time period
ESIM384 Installation and Configuration Manual v1.1
SMS text message content:
ssss_Coo:ON or ssss_out-name:ON
SMS
Value: ssss – 4-digit SMS password; oo – PGM output number, range – [1... 80]; out-name –
up to 16 characters PGM output name.
Example: 1111_Lights:ON
Menu path:
OK → mmmm → OK → PGM OUtPUtS → OK → out-name → ON → OK
EKB2
Value: mmmm – 4-digit master code; out-name – up to 16 characters PGM output name.
Enter parameter 61, PGM output number and parameter status value:
EKB3/
61 oo 1 #
EKB3W/
Value: oo – PGM output number, range – [01... 80].
EWKB4
Example: 61031#
ElDES
Config-
this operation may be carried out from the PC using the ELDES Configuration software.
uration
software
this operation may be carried out from the wireless keyfob if pre-assigned using the PC run-
EWK1/
EWK2 ning ELDES Configuration software.
SMS text message content:
ssss_Coo:OFF or ssss_out-name:OFF
SMS
Value: ssss – 4-digit SMS password; oo – PGM output number, range – [1... 80]; out-name –
up to 16 characters PGM output name.
Example: 1111_C2:OFF
Menu path:
EKB2 OK → mmmm → OK → PGM OUtPUtS → OK → out-name → OFF → OK
Value: mmmm – 4-digit master code; out-name – up to 16 characters PGM output name.
Enter parameter 61, PGM output number and parameter status value:
EKB3/
61 oo 0 #
EKB3W/
Value: oo – PGM output number, range – [01... 80].
EWKB4
Example: 61020#
ElDES
Config-
this operation may be carried out from the PC using the ELDES Configuration software.
uration
software
this operation may be carried out from the wireless keyfob if pre-assigned using the PC run-
EWK1/
EWK2 ning ELDES Configuration software.
SMS text message content:
ssss_Coo:ON:hr.mm.sc
SMS
Value: ssss – 4-digit SMS password; oo – PGM output number, range – [1... 80]; out-name
– up to 16 characters PGM output name; hr – hours, range – [00... 23]; mn – minutes, range
– [00... 59]; sc – seconds, range – [00... 59].
Example: 1111_C4:ON:10.15.35
this operation may be carried out from the wireless keyfob if pre-assigned using the PC run-
EWK1/
EWK2 ning ELDES Configuration software.
or ssss_out-name:ON:hr.mn.sc
75
EN 75
