Eldes ESIM384 Installation Manual page 150

Set protocol
Set data format as
Kronos, EGr100 or
SIa IP
Manage SIa IP data
format parameters
Set encryption key
for EGr100 data
format
attEntIon: It is necessary to restart the system locally by powering down and powering up the system the system or remotely (see 34.
rEMotE SYStEM rEStart) after changing the IP address or switching from tCP to UDP.
notE: Kronos Net/Kronos Lt software communicates via tCP protocol, while eGR100 middle-ware v1.2 and up supports both – tCP and
UDP protocols.
By default, if the initial attempt to transmit data to the monitoring station via GPRS network or ethernet method is unsuccessful, the sys-
tem will make up to 3 additional attempts. If all attempts are unsuccessful, the system will switch to next backup connection that follows in
the sequence and will attempt to transmit data until it is successfully delivered to the monitoring station.
150 150 EN
Enter parameter 42 and DnS2 server IP address:
EKB3/
42 add add add add #
EKB3W/
EWKB4 Value: add add add add – DNS2 server IP address
Example: 42065082119002#
ElDES
Config-
this operation may be carried out from the PC using the ELDES Configuration software.
uration
software
SMS text message content:
Server 1: ssss_SetGPRS:PROtOCOL:ptc
SMS
Value: ssss – 4-digit SMS password; ptc – protocol, range – [tCP... UDP].
Example: 1111_SETGPRS:PROTOCOL:UDP
Menu path:
Server 1: OK → iiii → OK → MS SettINGS → OK → IP SettINGS → OK → SeRVeR IP → OK →
EKB2
PROtOCOL → OK → tCP | UDP → OK
Server 2: ... → SeRVeR2 IP → OK → PROtOCOL→ OK → tCP | UDP → OK
Server 3: ... → SeRVeR3 IP → OK → PROtOCOL→ OK → tCP | UDP → OK
Value: iiii – 4-digit installer code.
Enter parameter 43 and protocol number/parameter 96, parameter number and
EKB3/
protocol number:
EKB3W/
Server 1: 43 0 # - tCP |
EWKB4
Server 2: 96 06 0 #
Server 3: 96 07 0 #
Example: 431#
ElDES
Config-
this operation may be carried out from the PC using the ELDES Configuration software.
uration
software
ElDES
Config-
uration this operation may be carried out from the PC using the ELDES Configuration software.
soft-
ware
ElDES
Config-
uration
this operation may be carried out from the PC using the ELDES Configuration software.
soft-
ware
ElDES
Config-
uration
this operation may be carried out from the PC using the ELDES Configuration software.
soft-
ware
43 1 # - UDP
- tCP | 96 06 1 # - UDP
- tCP | 96 07 1 # - UDP
ESIM384 Installation and Configuration Manual v1.1
.
