Eldes ESIM384 Installation Manual page 95

HOME: 27 C
o
!
HOME Panic
B. to turn a PGM output ON by a single touch, please touch the corresponding PGM output button. Notice the icon displayed on the button
changing from (represents PGM output's OFF state) to
the PGM output. No code is required for these actions. the maximum number of PGM outputs that can be shown on the Main menu is 5.
HOME: 27 C
o
Controls Fire
notE: If you do not wish to display either the Controls button or individual PGM output button in the main menu due to the security reasons,
you can alternatively access the Controls menu under the Settings menu secured with Master PIN code.
19.10.10. How to view event log using EWKB5
the event log feature allows the system to chronologically register the records regarding certain system events, such as alarms, arm/
disarm events etc. Using eWKB5 the user can view the complete event log.
to view the event log, please navigate through the menu as follows. Please, note that this action requires Master PIN code.
HOME: 27 C
o
HOME Quick Arm
HOME: 27 C
o
Bypass Events
For more details on event log feature, please refer to section 28.1. Event log
ESIM384 Installation and Configuration Manual v1.1
01:19
Fire Controls Settings
01:19
Control1 Control2 Settings
01:19
Panic Fire Settings
01:19
Zones Outputs Faults
Control1
Control2
(represents PGM output's ON state). touching the button again will turn OFF
1
4
7
C
Events from 1 - 16
Disarmed over KEYBOARD: HOME
User1
2016.09.06 10:40
Zone Alarm: HOME, Alarm Zone1
2016.09.06 10:39
Stay Armed over KEYBOARD: HOME
User1
2016.09.06 09:47
Disarmed over KEYBOARD: HOME
2 3
5 6
Master PIN
8 9
0
95
EN 95
