Eldes ESIM384 Installation Manual page 19

notE:
the system does NOt support 2-wire smoke detectors.
type 3
5
M Z COM
EOL 5.6K
3.3K
TAMPER
NC
8-Zone mode: tamper
and 5,6KΩ end-of-line
resistor and 3,3KΩ
end-of-line resistor
with normally closed
contact.
type 4
6
M Z COM
5.6K
3K
NC
3.3K
C
NC
AtZ mode: 5,6KΩ
end-of-line resistor
and normally closed
contact with 3,3KΩ
end-of-line resistor
and normally closed
contact
type 5
7
M Z COM
EOL 5.6K
5.6K 3.3K
C
TAMPER
NC NC
C
AtZ mode: tamper,
5,6KΩ end-of-line
resistor, 5,6KΩ
end-of-line resistor
with normally closed
contact and 3,3KΩ
end-of-line resistor
with normally closed
contact.
See also 14.3. 8-Zone Mode and 14.4. atZ (advanced technology Zone) Mode.
ESIM384 Installation and Configuration Manual v1.1
example of motion detector wiring
Z COM
5.6K
NC
3.3K
NC
5,6 k 3,3 k
TAMP
example of magnetic door contact (Z1) and glass break sensor (Z9) wiring
Z COM
EOL 5.6K
5.6K 3.3K
TAMPER
NC NC
NC
example of motion detector (Z1) and magnetic door contact (Z9) wiring
5,6 k 5,6 k 3,3 k
COM
NC
TAMP
Z COM
EOL 5.6K
5.6K 3.3K
TAMPER
NC NC
COM
GND
NC
+Vin
COM
COM
Magnet
NC
NC
Magnet
GND
+Vin
GND
+Vin
COM
19
