Interpreting LEDs
Step
Related Information
"Checking for Faults" on page 27
■
"Performing Advanced Troubleshooting" on page 37
■
"Clear a Fault Manually" on page 43
■

Front Panel Controls and LEDs

No. LED
1 System Server
Locate indicator
and button
(white)
2 System Fault
(Service Action
Required) LED
(amber)
3 System OK
Indicator (green)
34 SPARC T8-2 Server Service Manual • June 2019
Description
if a component is faulty, see "Identify Faulted
Components" on page 29.
Icon or Label Description
You can turn on the Locate indicator to identify a particular server. When lit, the LED
displays as a fast blink. The blinking will time out after 15 minutes. Turn on the Locate
indicator by pressing the Locate button, or see
The fmadm faulty command provides details about any faults that cause this indicator to
light. See "Identify Faulted Components" on page
Under some fault conditions, individual component fault LEDs are lit in addition to the
Service Action Required LED.
Indicates these conditions:
Links
■ "Servicing PCIe Cards" on page 119
■ "Servicing the Motherboard" on page 147
"Locate the Server" on page
29.
50.
