222 C 3: D
HAPTER EVICE
Connecting and
Managing Analog
Devices
Adding a 4-Port
Analog Terminal Card
C
ONFIGURATION
A 4-Port Analog Terminal Card or a Single-Port Analog Terminal Adapter
(ATA) allows ordinary analog (2500-series compliant) telephones,
including cordless telephones and Group-3 facsimile devices, to operate
with NBX systems.
Certain limitations apply because of the differences between an analog
device and the custom NBX Telephone:
A user dials 500, then ** on a telephone connected to an ATA to gain
■
access to voice mail.
A telephone can make or answer only one call. The second incoming
■
call goes to voice mail.
ATC ports and ATAs support call transfer.
■
This section discusses these topics:

Adding a 4-Port Analog Terminal Card

■
Adding a Single-Port Analog Terminal Adapter (ATA)
■
Modifying an Analog Terminal Port
■
Removing an Analog Terminal Adapter
■
Viewing The Status of an Analog Terminal Adapter
■
To add a 4-Port Analog Terminal Card to the NBX system using
Auto Discovery:
1 In the NBX NetSet - Main Menu window, click System Configuration. The
System Configuration dialog box (Figure 70) appears.
2 Click System-wide. The System Settings dialog box (Figure 71) appears.
3 Click the Auto Discover Telephones check box to select it.
4 Click OK.
5 Insert the 4-Port Analog Terminal Card into the chassis.
6 Wait 1 minute for the system to discover the card.
7 In the NBX NetSet - Main Menu window, click Device Configuration.
8 In the Device Configuration dialog box, click the ATA tab. (See Figure 76.)
9 The four ports of the 4-Port Analog Terminal Card appear in the list of
ATAs, along with the ports of any previously discovered 4-Port Analog
Terminal Cards, and any previously discovered Single-Port Analog
Terminal Adapters (ATAs).
