224 C 3: D
HAPTER EVICE
Adding a Single-Port
Analog Terminal
Adapter (ATA)
C
ONFIGURATION
Table 37 MAC Addresses of Analog Terminal Adapter Ports (3C10117C)
ATA Card or Port
4-Port ATA Card
Port 1
Port 2
Port 3
Port 4
The extensions that are assigned to these ports by the NBX system may
not be in order. For example, if the NBX system assigns extensions 7258,
7259, 7260, and 7261 to the ATC ports, it might assign 7258 to port 3.
To determine the extension assigned to any port on a 3C10117C ATC:
1 Click the ATA tab.
2 Look for the combination of MAC address and port number that you
want. The extension associated with the port is in the first column (Ext.).
After you have added the Analog Terminal Card, you can configure the
parameters for each of the four ports. See "Modifying an Analog
Terminal Port" later in this chapter.
To add a Single-Port Analog Terminal Adapter (ATA) to the NBX system:
1 In the NBX NetSet - Main Menu window, click Device Configuration . The
Device Configuration dialog box appears (Figure 49).
2 Click the ATA tab. The ATA dialog box appears (Figure 76).
MAC Address
00:e0:bb:00:f8:c8
00:e0:bb:00:f8:c8[1]
00:e0:bb:00:f8:c8[2]
00:e0:bb:00:f8:c8[3]
00:e0:bb:00:f8:c8[4]
