70 C 2: D P
HAPTER IAL
Figure 15 Devices Using Dial Plan Dialog Box
LAN
5 Select Normal to see which devices use table ID 1 (in this example) as the
Normal table.
6 Click Least Cost to see which devices use table ID 1 (in this example) as
the Least Cost table.
Each device can use only one normal and one least cost table.
7 To move a device to the Devices Using Table list, select it in the Devices
Not Using Table list and click <<.
To move a device to the Devices Not Using Table list, select it in the
Devices Using Table list and click >>.
8 Click Close.
Table 12 Devices Using Dial Plan Table Fields
Field
Dial Plan Table ID
Dial Plan Table Name
Table Usage
Devices Using Table
Devices Not Using Table
Purpose
The identification number of the dial plan table as
specified in the dial plan configuration file.
The name of the dial plan table.
The type of table (either Normal or Least Cost). To select
a type, click either Normal or Least Cost.
A list of devices using this Normal or Least Cost
Routing table.
A list of devices not using this Normal or Least Cost
Routing table.
