146 C 3: D
HAPTER EVICE
C
ONFIGURATION
b Connect one end of the power adapter to the underside of the
telephone and the other end to a source of AC power.
c Connect the telephone to the LAN. See Figure 44.
d Wait until an extension number appears in the telephone's display
panel.
e Record the extension number on the telephone's shipping box.
f Disconnect the telephone from the LAN.
g Disconnect power from the telephone.
h Place the telephone back in its shipping box.
The telephone can now be placed in the appropriate location based on
the telephone extension assignment the customer has chosen.
Adding a Telephone Manually
To add a new telephone manually:
1 In the NBX NetSet - Main Menu window (Figure 46), click Device
Configuration . The Device Configuration window appears (Figure 49),
displaying the Telephones tab.
Figure 49 Device Configuration Window — Telephones Tab
