3Com SuperStack 3 NBX Administrator's Manual page 147

2 Click Add . The Add Telephones dialog box appears (Figure 50).
Figure 50 Add Telephone Dialog Box
3 Fill in the fields with the appropriate values. See Table 23.
Table 23 Add Telephone Dialog Box Fields
Field
MAC Address
Channel Number
Device Name
Adding, Removing, and Modifying Telephones
Description
The hardware address assigned at the factory to each device.
MAC Address
To find the
look at the label on the bottom of the telephone.
When you type the address, use the format: XX:XX:XX:XX:XX,
where each X represents a hexadecimal digit (0–f).
If you are configuring a pcXset client, the MAC address is the
address of the network interface card in the computer that
hosts the pcXset client.
Not used when adding a telephone.
If you add a telephone that is connected to a 3C10117 ATC,
leave this field empty. If you modify the settings for a
telephone that is connected to a 3C10117 ATC, this field
contains N/A (not applicable).
The name that appears in device lists to help you identify this
device. You can use any word with up to 16 characters.
of an NBX Business Telephone,
147
