About this task
If IBM installs a tier 1 CRU at your request, you will be charged for the installation.
The illustrations in this documentation might differ slightly from your hardware.
Removing the compute node cover
Remove the compute node from the chassis unit and press the compute node cover releases to open and
remove the compute node cover.
About this task
Figure 6. Removing the cover from an IBM Flex System p270 Compute Node
To remove the compute node cover, complete the following steps:
Procedure
1. Read the Safety topic and the "Installation guidelines" on page 29.
2. Shut down the operating system on all partitions of the compute node, turn off the compute node,
and remove the compute node from the IBM Flex System Enterprise Chassis. See "Removing the
compute node from an IBM Flex System Enterprise Chassis" on page 31.
Chapter 6. Installing and removing components
33
