Table 7. IBM Flex System p270 Compute Node parts (continued)
Index Description
1 IBM Flex System 4-port 1 Gb Ethernet adapter
IBM Flex System 8-port 10 Gb converged adapter
1
1 IBM Flex System 2-port 10 Gb RoCE adapter
1 IBM Flex System 2-port 16 Gb Fibre Channel adapter
1 IBM Flex System 4-port 16 Gb Fibre Channel adapter
2 Management card (CCIN 52F6)
3 IBM Flex System 3 Gb SAS ETE adapter
4 Light path diagnostics panel
5 Bezel
5 OEM bezel
6 3.0V battery
Memory, 4 GB DDR3, 1066 MHz very low profile (VLP)
7
DIMM
Memory, 8 GB DDR3, 1066 MHz very low profile (VLP)
7
DIMM
Memory, 16 GB DDR3, 1066 MHz low profile (LP)
7
DIMM
Memory, 32 GB DDR3, 1066 MHz low profile (LP)
7
DIMM
7 DIMM filler
8 Cover (supports two disk drives)
8 Cover (supports two solid-state drives)
8 Cover (no drives supported)
9 177 GB SATA solid-state drive
10 Solid-state drive carrier
300 GB SAS small form factor disk drive and screws (4)
11
(option)
600 GB SAS small form factor disk drive and screws (4)
11
(option)
900 GB SAS small form factor disk drive and screws (4)
11
(option)
11 Disk drive filler
Service label
Light path label
Miscellaneous parts kit (left cam handle)
Miscellaneous parts kit (network adapter retention)
*The microprocessor removal tool is included with the system-board and chassis assembly FRU and microprocessor
parts kit FRUs. The microprocessor removal tool cannot be ordered independently.
CRU part number
(Tier 1)
49Y7902
00E1677
90Y3481
95Y2389
95Y2394
00E1882
00E7823
00J0455
33F8354
78P0501
78P1917
78P1915
78P1539
60H2962
00FW327
00FW329
00E9323
74Y9115
74Y9407
42D0628
49Y2023
00J0017
40K5928
00E9324
00J0140
81Y5203
94Y4866
