Installing The Compute Node In An Ibm Flex System Enterprise Chassis - IBM Flex System p270 Compute Node Installation And Service Manual

To replace and close the compute node cover, complete the following steps:
Procedure
1. Read the Safety topic and the "Installation guidelines" on page 29.
2. Lower the cover so that the pins on the sides of the cover slide down into the slots (as shown in the
preceding figure) at the front and rear of the compute node. Before you close the cover, verify that all
components are installed and seated correctly and that you have not left loose tools or parts inside the
compute node.
3. Slide the cover forward to the closed position until the releases click into place in the cover.
4. Install the compute node into the IBM Flex System Enterprise Chassis. See "Installing the compute
node in an IBM Flex System Enterprise Chassis."

Installing the compute node in an IBM Flex System Enterprise Chassis

Install the compute node in an IBM Flex System Enterprise Chassis to use the compute node.
About this task
Figure 51. Installing the compute node in an IBM Flex System Enterprise Chassis
Statement 21
CAUTION:
Hazardous energy is present when the compute node is connected to the power source. Always replace
the compute node cover before you install the compute node.
To install a compute node in an IBM Flex System Enterprise Chassis, complete the following steps:
92
Power Systems: IBM Flex System p270 Compute Node Installation and Service Guide
