22. Have the customer set the compute node IPv4 address and any static IPv6 addresses. Complete the
following steps:
a. Access the Chassis Management Module (CMM) web interface. For instructions, see Ethernet
connection (http://pic.dhe.ibm.com/infocenter/flexsys/information/topic/
com.ibm.acc.cmm.doc/remote_console_ethernet_connect_cmm.html).
b. In the menu bar, click Chassis Management. Then, in the drop-down menu, click Component IP
Configuration. From the Device Name list, select the compute node name to access property tabs
for the compute node. Set the address in the IPv4 property tab by using the information that is
recorded in step 6 on page 84 of this procedure. Set any static addresses in the IPv6 property tab
by using the information that is recorded in step 6 on page 84 of this procedure. For more
information about displaying the IP configuration of a compute node, see Chassis management
options (http://pic.dhe.ibm.com/infocenter/flexsys/information/topic/com.ibm.acc.cmm.doc/
cmm_ui_chassis_management.html).
23. Have the customer set the chassis and compute node level Serial over LAN (SOL) settings of the
compute node. Complete the following steps:
a. Access the Chassis Management Module (CMM) web interface. For instructions, see Ethernet
connection (http://pic.dhe.ibm.com/infocenter/flexsys/information/topic/
com.ibm.acc.cmm.doc/remote_console_ethernet_connect_cmm.html).
b. To set the Serial over LAN setting of the chassis, complete the following steps:
1) In the menu bar, click Chassis Management.
2) From the Chassis Management list, click Compute Nodes.
3) Click the Global Settings button.
4) In the Global Node Settings window, click the Serial Over LAN tab.
5) Set the Enable Serial Over LAN check box by using the information that is recorded in step 7
on page 85 of this procedure. Then, click OK to save the setting.
6) In the SOL Global Configuration window, click close.
c. To set the Serial over LAN setting of the compute node, complete the following steps:
1) From the Device Name list, click the compute node name to access the property tabs for the
compute node.
2) Click the General tab.
3) Set the Enable Serial Over LAN check box by using the information that is recorded in step 7
on page 85 of this procedure. Click apply to save the Serial Over LAN setting.
4) In the Node Properties window, click close.
24. Have the customer set the compute node system name. Complete the following steps:
a. Access the ASMI. For information about how to access the ASMI, see Chapter 5, "Accessing the
service processor," on page 27.
b. The system name was recorded in step 5 on page 84 of this procedure. If the correct system name
is not displayed near the top of the ASMI Welcome pane, set the system name by clicking
System Configuration > System Name.
25. Have the customer ensure that the Time-Of-Day setting is correct. Complete the following steps:
a. Access the ASMI. For information about how to access the ASMI, see Chapter 5, "Accessing the
service processor," on page 27.
b. Click System Configuration > Time Of Day.
c. Ensure that the Time-Of-Day is set to the NTP mode or that the Time-Of-Day has the correct time
in Coordinated Universal Time (UTC).
Note: If the Time-of-Day is set to the NTP mode, the ASMI center pane shows the following
message - Changing date/time is not allowed when the system is in NTP mode and you cannot
change the time. If the NTP mode is not set and the time is not correct in UTC, enter the correct
time and save. This operation can be completed only when the compute node is turned off.
