IBM Flex System p270 Compute Node Installation And Service Manual page 251

C1009XD0
Explanation: Message passing waiting period has begun
Response:
1. Search RETAIN tips and the firmware change history for the reference code to determine the recommended
actions. If a firmware update is needed, see Updating the firmware.
2. Replace the system-board, as described in Replacing the system-board and chassis assembly.
C1009XD4
Explanation: Starting elastic interface calibration
Response:
1. Search RETAIN tips and the firmware change history for the reference code to determine the recommended
actions. If a firmware update is needed, see Updating the firmware.
2. Replace the system-board, as described in Replacing the system-board and chassis assembly.
C103A1XX
Explanation: Hypervisor code modules are being transferred to server storage
Response:
1. Search RETAIN tips and the firmware change history for the reference code to determine the recommended
actions. If a firmware update is needed, see Updating the firmware.
2. Replace the system-board, as described in Replacing the system-board and chassis assembly.
C103A2XX
Explanation: Hypervisor data areas are being built in server storage
Response:
1. Search RETAIN tips and the firmware change history for the reference code to determine the recommended
actions. If a firmware update is needed, see Updating the firmware.
2. Replace the system-board, as described in Replacing the system-board and chassis assembly.
C103A3XX
Explanation: Hypervisor data structures are being transferred to server storage
Response:
1. Search RETAIN tips and the firmware change history for the reference code to determine the recommended
actions. If a firmware update is needed, see Updating the firmware.
2. Replace the system-board, as described in Replacing the system-board and chassis assembly.
C1009XD0 • C103A3XX
Chapter 8. Troubleshooting
239
