Page 152 of 408 Installing System Controller Cards
553-3021-210 Standard 7.00
Note 1: With new connectors, push very firmly until a definite 'click' is
heard. Pull gently on the connection to make sure it is secure.
Note 2: The top connector on the SSC card is for expansion
cabinets"1" and "3". The lower connector is for expansion cabinets "2"
and "4".
5 Replace the standoffs on the SSC card with the standoffs
supplied with the IP daughterboard.
6 Record the MAC address found on the back of the daughterboard
of the expansion cabinets. This will be needed later to perform the
software installation.
7 Connect the faceplate LED to the 3 pin receptacle on
daughterboard See Figure 60 on page 153 for exact location.
8 Mount the daughterboard onto card by inserting the plastic post
into designated slot on the daughterboard. See Figure 57 on page
149 for exact positioning.
Note: Tip the daughterboard down over the post and press down onto
the two standoffs.
9 Firmly press the daughterboard down on connector pin to secure
in place.
10 Route expansion cable through the cable router on the SSC card.
11 Insert the SSC card into slot "0" of the Main Option 11C cabinet.
Lock card into face plate latches.
12 Route the cable through the Cable Routing Guide under the Main
cabinet.
Note: Be sure to wrap the cable a minimum of one complete loop
around the Cable Routing Guide.
—————————— End of Procedure ——————————
Note: The use of the EMC clip is required for 100BaseT and is optional
on 100BaseF connections.
