xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch CLI Reference Guide

Multiple Spanning Tree Protocol (MSTP) Commands

This Switch supports three versions of the Spanning Tree Protocol: 802.1D STP, 802.1w Rapid STP and 802.1s
MSTP. Multiple Spanning Tree Protocol, or MSTP, is a standard defined by the IEEE community that allows multiple
VLANs to be mapped to a single spanning tree instance, which will provide multiple pathways across the network.
Therefore, these MSTP configurations will balance the traffic load, preventing wide scale disruptions when a single
spanning tree instance fails. This will allow for faster convergences of new topologies for the failed instance. Frames
designated for these VLANs will be processed quickly and completely throughout interconnected bridges utilizing
either of the three spanning tree protocols (STP, RSTP or MSTP). This protocol will also tag BDPU packets so
receiving devices can distinguish spanning tree instances, spanning tree regions and the VLANs associated with
them. These instances will be classified by an instance_id. MSTP will connect multiple spanning trees with a Common
and Internal Spanning Tree (CIST). The CIST will automatically determine each MSTP region, its maximum possible
extent and will appear as one virtual bridge that runs a single spanning tree. Consequentially, frames assigned to
different VLANs will follow different data routes within administratively established regions on the network, continuing
to allow simple and full processing of frames, regardless of administrative errors in defining VLANs and their
respective spanning trees. Each Switch utilizing the MSTP on a network will have a single MSTP configuration that will
have the following three attributes:
a) A configuration name defined by an alphanumeric string of up to 32 characters (defined in the config stp
mst_config_id command as name <string>).
b) A configuration revision number (named here as a revision_level) and;
c) A 4096 element table (defined here as a vid_range) which will associate each of the possible 4096 VLANs
supported by the Switch for a given instance.
To utilize the MSTP function on the Switch, three steps need to be taken:
a) The Switch must be set to the MSTP setting (config stp version)
b) The correct spanning tree priority for the MSTP instance must be entered (config stp priority).
c) VLANs that will be shared must be added to the MSTP Instance ID (config stp instance_id).
The Multiple Spanning Tree Protocol commands in the Command Line Interface (CLI) are listed (along with the
appropriate parameters) in the following table.
Command
enable stp
disable stp
config stp version
config stp
config stp ports
create stp instance_id
config stp instance_id
delete stp instance_id
config stp priority
config stp mst_config_id
config stp mst_ports
show stp
show stp ports
show stp instance
Parameters
[mstp | rstp | stp]
{maxage <value 6-40> | maxhops <value 6-40> | hellotime <value 1-2> |
forwarddelay <value 4-30> | txholdcount <value 1-10> | fbpdu [enable | disable]
| nni_bpdu_addr [dot1d | dot1ad]}(1)
<portlist> { externalCost [ auto | <value 1-200000000> ] | hellotime <value 1-2> |
migrate [yes | no ] | edge [ true | false | auto ] | p2p [ true | false | auto ] | state
[enable | disable ] | restricted_role [true | false] | restricted_tcn [true | false ] |
fbpdu [enable | disable ] }(1)
<value 1-15>
<value 1-15> [add_vlan | remove_vlan] <vidlist>
<value 1-15>
<value 0-61440> instance_id <value 0-15>
{revision_level <int 0-65535> | name <string>}(1)
<portlist> instance_id <value 0-15> {internalCost [auto | <value 1-200000000>]
priority <value 0-240>}(1)
{<portlist>}
{<value 0-15>}
