2300 Drive drive_ID ready for service
Explanation: Drive is ready for removal. Possible causes:
v Dismount request from operator
v Presence of an unreliable drive (failed or undiscoverable yet detected by SES)
v Presence of an unsupported drive
System action: Drive fault light turns on, indicating "ready to remove" state. By default, the SAS RAID Module
system information indicator is turned on and the operator is notified of this alert by e-mail. Alert clears when the
drive is removed or the drive mount state changes (to unmounted or mounted).
Operator response: Remove the drive.
2320 Drive carrier tray_ID ready for service
Explanation: Tray contains no mounted drives and at least one dismounted drive
System action: Tray fault light turns on, indicating "ready to remove" state. Drive fault lights of any associated
failed drives turn on, indicating "ready to remove" state. By default, the SAS RAID Module system information
indicator is turned on and the operator is notified of this alert by e-mail. Alert clears when tray is removed.
Operator response: Remove the tray
2322 Drive carrier tray_ID ready for service
Explanation: The operator set the tray mount state to DISMOUNTED.
System action: Tray fault light turns on, indicating "ready to remove" state. By default, the SAS RAID Module
system information indicator is turned on and the operator is notified of this alert by e-mail. Alert clears when tray is
removed or mount state changes to MOUNTED.
Operator response: Acknowledge to clear the alert immediately. Remove the tray.

Disk drive alerts

The alerts in this section are generated to inform the operator of changes in drive
status.
0317 Unresponsive drive inserted in location drive_ID
Explanation: SES detects drive presence, but no target port login detected after appropriate delay.
System action: By default, the SAS RAID Module system information indicator is turned on and the operator is
notified of this alert by e-mail. Alert clears when drive connectivity is established or the drive is removed.
Operator response: Check drive connections or replace drive (see "Replacing a failed drive" on page 167).
This alert can be masked so that it does not trigger the SAS RAID Module system information indicator.
