0215 • 1203
0215 Battery battery_ID firmware update complete
Explanation: When the system boots up or a battery is inserted, the controller checks the battery firmware level. If
the firmware does not match the expected version, the controller automatically performs a firmware update and then
generates this alert to indicate that a firmware mismatch was detected and corrected.
System action: By default, the SAS RAID Module system information indicator is not turned on and the operator is
not notified of this alert by e-mail. Alert clears automatically after 120 seconds.
Operator response: Acknowledge to clear the alert immediately.
Battery battery_ID nearing expiration date (date)
1200
Explanation: The battery has expiration date tracking, and the expiration date is between 14 and 90 days from now.
System action: By default, the SAS RAID Module system information indicator is turned on and the operator is
notified of this alert by e-mail. Alert clears when battery is removed or battery status changes to "expiration
imminent" (alert 1201).
Operator response: Replace the battery (see "Replacing a Battery Backup Unit" on page 177).
This alert can be masked so that it does not trigger the SAS RAID Module system information indicator.
Battery battery_ID expiration date (date) imminent
1201
Explanation: The battery has expiration date tracking, and the expiration date is less than 15 days from now.
System action: By default, the SAS RAID Module system information indicator is turned on and the operator is
notified of this alert by e-mail. Alert clears when the battery is removed or battery status changes to "expired" (alert
1202).
Operator response: Replace the battery (see "Replacing a Battery Backup Unit" on page 177).
This alert can be masked so that it does not trigger the SAS RAID Module system information indicator.
1202 Battery battery_ID expired (date)
Explanation: The battery has expiration date tracking, and the battery expiration date has passed.
System action: By default, the SAS RAID Module system information indicator is turned on and the operator is
notified of this alert by e-mail. Alert clears when the battery is removed.
Operator response: Replace the battery (see "Replacing a Battery Backup Unit" on page 177).
This alert can be masked so that it does not trigger the SAS RAID Module system information indicator.
1203 Battery battery_ID failed (code failure_code)
Explanation: No working battery is detected. Possible causes include:
v Battery communication error or timeout
v Missing battery
v Charging system failure
v Battery has passed its expiration date
v Battery temperature out of Spec range
System action: By default, the SAS RAID Module system information indicator is turned on and the operator is
notified of this alert by e-mail. Alert clears when the battery is removed.
Operator response: Correct the problem. Ensure that a working battery is in place (see "Replacing a Battery Backup
Unit" on page 177).
This alert can be masked so that it does not trigger the SAS RAID Module system information indicator.
126
