MERLIN LEGEND Communications System R7.0
System Manager's Quick Reference 555-670-119
Managing the System
Managing Telephones
You must busy-out the module before you add or remove a CTI link and then
restore the module after the CTI link has been added or removed. These
procedures are typically reserved for Lucent Technologies technicians.
Release 5.0 and later systems support the use of an MLX port as a CTI link on
Hybrid/PBX mode systems. The CTI link feature allows CTI applications to
interact with the MERLIN LEGEND Communications System over a LAN. The
CTI link is the system's hardware and software interface to the Lucent
Technologies PassageWay Telephony Services product, which supports the
Windows® 95, Windows NT®, Windows 3.1, Windows 3.11 for Workgroups,
Apple® Macintosh® OS and UNIX® systems platforms on the client side. CTI
link circuitry connects to an MLX port on the system and to a LAN server using
Novell NetWare (releases 3.12, 4.1, and 4.11) or Windows NT software.

Printing a System Information Report

Use this procedure to print or view a System Information report in order to
determine the slot number of a 408 GS/LS-MLX, 408 GS/LS-ID-MLX, 008 MLX,
or 016 MLX module.
Console Procedure
PC Procedure

Busying Out the MLX Module

Use this procedure to busy-out the MLX module. If the busy-out procedure is
taking a long time to complete, someone is using an extension or facility on the
module. The actual time it takes to busy-out or restore a module is less than one
second.
To print system information:
More
Print SysSet-up
To print system information:
To save report on disk:
below console simulation screen
To view the report on the screen:
+
Exit
select
GOTO FLOPPY
Issue 1
April 1999
87
from
