2 Control Unit Configuration
Numbering the System
3. In the last column, identify the type of equipment connected to the jack or
the ISDN terminal adapter connected to the jack. Also, record the person,
location, or function if desired.
Proceed to the next section,
Jacks for Analog Multiline Telephones
Use these instructions only if the system includes 408, 408 GS/LS or 008
modules. Otherwise, skip to the next section,
Applications''.
Certain features should be used differently when a GPA (General-Purpose
Adapter) is connected to an analog multiline telephone and configured using the
Automatic setting. These configurations include:
GPA connected to an answering machine and an analog multiline
telephone with Auto Answer All button programmed.
GPA connected to an analog multiline telephone programmed for voice
and data.
NOTE: NOTE: NOTE:
An MLX telephone with an MFM installed is preferred for these applications.
When these configurations are used, lift the handset before activating features
that automatically turn on the speakerphone. Examples of features that
automatically turn on the speakerphone are Authorization Codes, Auto Dial, Last
Number Dial, and Saved Number Dial.
Assign analog extension jacks for all remaining non-operator analog multiline
telephones in the system.
Planning Form Instructions
On Form 2a, mark the extension assignments for the remaining analog multiline
telephones:
1. In the Jack Type column, make sure A is checked next to the logical ID for
each analog extension jack.
2. In the Person, Location, or Function column, identify each analog multiline
telephone by the users name, location, or function.
If an MLX telephone will be connected to a desktop video system in
a passive bus configuration, check the box in the Pass. Bus column.
Also make an entry on Form 4d, MLX Telephone, to indicate that the
MLX telephone is in a passive bus configuration and note the type of
endpoint to which the MLX telephone is connected.
If a digital data or video system is connected to the jack, enter the
extension number in the MLX Telephone Ext. No. column.
''Jacks for Analog Multiline Telephones''.
