Assigning Lines/Trunks to Data and Video Stations
Forms Needed
Data Form 1a, Modem Data Stations
Data Form 1b, Data Stations
Form 4e, MFM Adjunct: MLX Telephone
Form 5c, MFM Adjunct: DLC
Planning Form Instructions
You should have already filled out preliminary information on Forms 4e and 5c
when you planned voice communications. The lines/trunks for MLX telephones
have already been assigned.
There are two different forms for data stations:
Data Form 1a. Use this form for modem data-only stations and for modems
used to communicate with the local host computer and to communicate
with a workstation on a LAN.
Data Form 1b. Use this form for ISDN terminal adapters and ISDN terminal
adapter data stations used to communicate with the local host computer
and to communicate with a workstation on a LAN.
Make enough copies of each data form so that you can complete one form for
each data station. Complete each form:
1. From Form 2a, System Numbering: Extension Jacks, obtain the
identification information for each data station.
2. Record the information on the appropriate data form (2a or 2b) for each
data station and for each modem and ISDN terminal adapter used to
communicate with a local host computer or with a workstation on a LAN:
a.
b.
c.
d.
In the Logical ID space, write the logical ID for each extension.
In the Extension No. space, write the extension number for each
extension.
In the Person or Location space, write the name of the person or the
location of the data equipment.
Under the Data Station Use heading, indicate the purpose of the
data station by checking one of the following boxes: Individual use,
Local host computer, or LAN workstation.
