MERLIN LEGEND Communications System Release 5.0
System Planning 555-650-112
3 Lines/Trunks
Selecting Line/Trunk Options
Delete Digits
Add Digits
Signaling
Invalid Destination
Trunks Included in Blocks
These options are assigned to blocks of trunks. A maximum of two blocks is
permitted.
If you want to allow Remote Access on DID trunks, one of the telephone numbers
assigned by the telephone company must match the remote access dial code.
The factory setting is 889.
If two-way DID service is available from the local telephone company, it is typically
set up as Tie Trunks service.
For detailed information about DID trunks and these options, see the Equipment
and Operations Reference.
NOTE: NOTE: NOTE:
If the system will have two blocks, make a copy of Form 3d and write the
block number in the Block Number space. Check with the local telephone
company to determine the number of digits sent.
Planning Form Instructions
1. On Form 3d, under the Type heading, do one of the following:
2. Under the Expected Digits heading on Form 3d, do one of the following:
3. Compare the number of digits sent by the local telephone company to the
number of digits in the system numbering plan, and do one of the following:
To keep the factory setting, check the Wink-Start box.
To change the type, check the Immediate-Start box.
To show that the telephone company sends the factory-set number
of digits, check the box labeled 3 .
To show the number of digits sent by the telephone company, check
one of the boxes labeled 1 , 2 , or 4 .
If the system's numbering plan matches the number of digits sent by
the telephone company, check 0 (the factory setting) under the
Delete Digits and Add Digits headings.
Issue 1
June 1997
Page 3-38
