Product Information Label

The product information label on the underside of the unit contains the following
information about each specific unit:

Technical Specifications

Serial Interface
(Device)
Serial Interface
(Console)
Network Interface
Power Supply
Power Consumption
Dimensions
Weight
Temperature
Relative Humidity
Heat Flow Rate
You can install the SLC either in an EIA-standard 19-inch rack (1U tall) or as desktop
unit. The SLC uses convection cooling to dissipate excess heat.
SecureLinx SLC User Guide
Part Number
Serial Number Bar Code
Serial Number and Date Code
Regulatory Certifications and Statements

Table 3-1. SLC Technical Specifications

RJ45-type 8-conductor connector (DTE)
Speed software selectable (300 to 115,200 baud)
RJ45-type 8-pin connector (DTE)
Speed software selectable (300 to 115,200 baud)
10Base-T/100Base-TX RJ45 Ethernet
Universal AC power input: 100-240 VAC, 50 or 60 Hz
IEC-type regional cord set included
DC power input :
-24 to -60 VDC
Less than 20 watts
1U, 1.75 in x 17.25 in x 12 in
10 lbs or less, depending on the options
Operating: 0 to 50 °C (32 to 122 °F), 30 to 90 %RH, non-condensing
Storage: -20 to 70 °C (-4 to 158 °F), 10 to 90 %RH, non-condensing
Operating: 10% to 90% non-condensing; 40% to 60% recommended
Storage: 10% to 90% non-condensing
68 BTU per hour
3: Installation
19
