Lantronix SecureLinx SLC48 User Manual page 123

Host
User
Host & Login for Import
Import via
Host
Filename
Path
Login
Password/Retype
Password
Exported SSH Keys
User
Key Name
Key Type
Number of Bits
Passphrase/Retype
Passphrase
SECSH Format
Host and Login for Export
Export via
Host
Path
Login
Password/Retype
Password
SecureLinx SLC User Guide
Host name or IP address from which the SSH connections to the
SLC will be made.
The User ID of the user being given secure access to the SLC.
Select SCP or FTP as the method for importing the SSH keys.
SCP is the default.
IP address of the remote server from which to SCP or FTP the
public key file.
Name of the public key file (for example, mykey.pub).
Optional pathname to the public key file.
User ID to use to SCP or FTP the file.
Password to use to SCP or FTP the file.
User ID of the person given secure access to the remote server.
Name of the key. This will generate the public key filename (e.g.,
<keyname>.pub).
Select either the RSA or the DSA encryption standard. RSA is the
default.
Select the number of bits in the key (512 or 1024). The default is
512.
Optionally, enter a passphrase associated with the key. The
passphrase may have up to 50 characters. The passphrase is an
optional password that can be associated with an SSH key. It is
unique to each user and to each key.
Indicate whether the keys will be exported in SECSH format (by
default the key is exported in OpenSSH format).
Select the method (SCP, FTP, or Cut and Paste) of exporting the
key to the remote server. Cut and Paste, the default, requires no
other parameters for export.
IP address of the remote server to which the SLC will SCP or FTP
the public key file.
Optional path of the file on the host to SCP or FTP the public key
too.
User ID to use to SCP or FTP the public key file.
Password to use to SCP or FTP the public key file.
10: User Authentication
123
