Device Port - Slp Commands; Interacting With A Device Port - Lantronix SecureLinx SLC48 User Manual

Control Outlet
2. Click Apply.

Device Port - SLP Commands

The following CLI commands correspond to the web page entries described above.
To send commands to (or control) a device connected to an SLC device port over
the serial port:
Note:
set command <Device Port # or Name or List> <one or more
parameters>
Parameters:

Interacting with a Device Port

Once a device port has been configured and connected to an external device such as the
console port of an external server, the data received over the device port can be
monitored at the command line interface with the connect listen command, as
follows:
To connect to a device port to monitor it:
connect listen deviceport <Port # or Name>
In addition, you can send data out the device port (for example, commands issued to an
external server) with the connect direct command, as follows:
SecureLinx SLC User Guide
Number of the outlet to be controlled (of 1-8 for the SLP8 or
1-16 for the SLP16) and select the command for the outlet
(No Action, Power On, Power Off, Cycle Power). No
Action is the default.
Currently the only type of device supported for this type of interaction is the SLP.
slp auth login <User Login>
Establishes the authentication information to log into the SLP attached
to the device port.
slp restart
Issues the CLI command the SLP uses to restart itself.
slp outletcontrol state <on|off|cyclepower> [outlet
<Outlet #>]
Outlet # is 1-8 for SLP8 and 1-16 for SLP16.
The outletcontrol parameters control individual outlets.
slp outletstate [outlet <Outlet #>]
The outletstate parameter shows the state of all outlets or a single
outlet.
slp envmon
Displays the environmental status (e.g., temperature and humidity) of
the SLP.
slp system
Provides system information for the SLP.
8: Device Ports
73
