C : A d a p t e r s
C : A d a p t e r s
The serial device ports of the SLC products match the RJ45 pinouts of the console ports
of many popular devices found in a network environment. The SLC uses conventional
straight-through Category 5 fully pinned network cables for all connections when used
with Lantronix adapters. These cables and adapters in various lengths are available from
Lantronix.
The serial device ports of the SLC products match the RJ45 pinouts of the console ports
of many popular devices found in a network environment. The SLC uses conventional
Category 5 fully pinned network cables for all connections when used with Lantronix
adapters. These cables and adapters are available from Lantronix. The cables are
available in various lengths.
In most cases, you will need an adapter for your serial devices. Lantronix offers a variety
of RJ45-to-serial connector adapters for many devices. These adapters convert the RJ45
connection on the SLC to a 9-pin or 25-pin serial connector found on other
manufacturers' serial devices or re-route the serial signals for connections to other
devices that use RJ45 serial connectors.
Please check the cabling database on the Lantronix website at
for suggested cables and adapters for commonly used serial devices.
The console port is wired the same way as the device ports and has the same signal
options.
Note: You can view or change the console port settings using the LCDs and
pushbuttons on the front panel, the Console Port web page, or the command line
interface show console port and set consoleport commands.
The adapters illustrated below are compatible with the Lantronix SLC models.
SecureLinx SLC User Guide
a n d P i n o u t s
a n d P i n o u t s
http://www.lantronix.com
211
