Connection Configuration

To create a connection:
1. From the main menu, select Connections. The following page displays:
2. For a device port, enter the following:
Port
Data Flow
SecureLinx SLC User Guide
The number of the device port you are connecting.
This device port must be connected to an external
serial device and must not have command line
interface logins enabled, be connected to a
modem, or be running a loopback test.
Note: To see the current settings for this device
port, click the Settings link.
Select the arrow showing the direction
(bidirectional or unidirectional) the data will flow in
relationship to the device port you are connecting.
9: Connections
86
