Obtain from DHCP
Obtain from
BOOTP
Specify
IP Address (if
specifying)
Subnet Mask
Eth1 and Eth2
Mode
3. Enter the following:
Gateways and Hostname
Default Gateway
DHCP Gateway
Precedence
SecureLinx SLC User Guide
Acquires IP address, subnet mask, and gateway from the
DHCP server. (The DHCP server may not provide the
gateway, depending on its setup.) This is the default
setting. If you select this option, skip to step 4.
Lets a network node request configuration
information from a BOOTP "server" node. If you
select this option, skip to step 4.
Lets you manually assign a static IP address, generally
provided by the system administrator.
Enter an IP address that will be unique and valid on your
network. There is no default.
Enter all IP addresses in dot-quad notation. Do not use
leading zeros in the fields for dot-quad numbers less than
100. For example, if your IP address is 172.19.201.28, do
not enter 028 for the last segment.
Note: Currently, the SLC does not support configurations
with the same IP subnet on multiple interfaces (Ethernet or
PPP).
If specifying an IP address, enter the network segment on
which the SLC resides. There is no default.
Select the direction (full-duplex or half-duplex) and speed
(10 or 100Mbit) of data transmission. The default is Auto,
which allows the Ethernet port to auto-negotiate the speed
and duplex with the hardware endpoint to which it is
connected.
IP address of the router for this network.
If this has not been set manually, any gateway acquired by
DHCP for Eth1 or Eth2 displays.
All network traffic that matches the Eth1 IP address and
subnet mask is sent out Eth1. All network traffic that
matches the Eth2 IP address and subnet mask is sent out
Eth 2.
If you set a default gateway, any network traffic that does
not match Eth1 or Eth2 is sent to the default gateway for
routing.
Gateway acquired by DHCP for Eth1 or Eth2.
Indicates whether the gateway acquired by DHCP or the
default gateway takes precedence. The default is DHCP
Gateway. If the DHCP Gateway is selected and both Eth1
and Eth2 are configured for DHCP, the SLC gives
precedence to the Eth1 gateway.
6: Basic Parameters
