Console Server

For this situation, the SLC is configured so that the user can manage a number of servers
or pieces of network equipment using their console ports. The device ports on the SLC
are connected to the console ports of the equipment that the user would like to manage.
To manage a specific piece of equipment, the user can Telnet or SSH to a specific port or
IP address on the SLC and be connected directly to the console port of the end server or
device. To configure this setup, set the Enable Telnet In or Enable SSH In option on the
Device Ports – Settings web page for the device port in question. The user can
implement an extra remote management capability by adding a modem to one of the
device ports and setting the Dial-in option in the Modem Settings section of the Device
Ports – Settings web page. A user could then dial into the SLC using another modem and
terminal emulation program at a remote location.
Switch
Router
SecureLinx SLC User Guide
Web Server
Serial Terminal
Sessions
SLC Console Manager
Modem
9: Connections
Telnet/SSH
Sessions
PC
PC
PC
85
