8.

Specifications

Spectrum Analysis
Frequency Range
Frequency Span
Frequency Step
Resolution Bandwidth (-
3dB)
Level Measurement Range
Accuracy
Measurements
Measurement Detector
Reference Level
Markers
Analog TV Measurement
Standards
Color Standards
Frequency Step
Hum Measurement
C/N
Level Measurement Range
Accuracy
Measurements
308
S7200 TV Signal Analyzer Operation Manual
5 MHz ~ 1220MHz (TV), 950 MHz ~ 2150 MHz
(Satellite)
0 MHz ~ 1215MHz (TV), 0MHz ~ 1200 (Satellite)
1 kHz (TV & Satellite)
30kHz, 100kHz, 300kHz, 1MHz, 3MHz
-50dBmV ~ +60dBmV (TV), -30dBmV ~ +60dBmV
(Satellite)
Of <1.5 dB
Positive Peak, Negative Peak, Sample, Average,
RMS
-30dBmV ~ +60dBmV
2 vertical markers
B/G, I, D/K, L/L´, M/N
PAL, SECAM, NTSC
10 kHz
1% ~ 15%
> 50dB
-30dBmV ~ +60dBmV
Of < 1.5 dB
