: 22KHz signal status icon. When user uses the DisEqC protocol, this signal need
open.
: CA(Condition Access) card icon. Icon
recognition, icon
programs can be decoded.
: TS-ASI input/output status icon, indicator the ASI function is working.
: SSD (Solid State Disk) icon.
Different battery icon instruction:
：Adaptor connected;
：Full battery;
：Low battery;
：Empty battery.
: The soft button can not work status.
: The button is unactive status.
: The button is active status.
S7200 TV Signal Analyzer Operation Manual
means the smart card successful recognition. The related
means CA module successful
