Figure 6-76 Full Screen Display Picture
The realtime analysis option offers four submenus: video/audio information and
bandwidth. The V/A information option is the same as the Figure 6-75 content.
The bandwidth shows the selected program bandwith information in the program
list which has been highlighted. The yellow curve is the video BW rate curve if the
video information is included in the program. The green curve is the first audio
BW curve if the audio information is included in the program. The purple curve is
the second audio BW curve if the second audio information is included in the
program. The horizontal coordinate is description the percentage of the courrent
for a period of time, and the left vertical coordinate is description the percentage
of the BW percent of the video in the program. The right vertical coordinate is
description the percentage of the BW percent of the audio in the program. If the
program is not a digital TV program, no curve will be displayed.
