AD INSTRUMENTS S7200 TV Signal Analyzer Operation Manual

5.5. Create and Edit a Channel Plan

S7200 support cable, terrestrial and satellite broadcast measurement. The cable
and terrestrial broadcast channel plan similar, but the satellite channel plan has
many difference with the cable and terrestrial channel plan. S7200 provide two
test mode: cable and terrestrial boradcast use one mode, satellite use another
mode. In different test mode, press the button can enter different channel
plan creat screen.

5.5.1. Create Cable and Terrestrial Channel Plan

Under the cable and terrestrial test mode, press button on the front panel
below the screen, the channel plan menu comes up. The available channel Plans
are in the left window and identified by a customizable naming structure. The
asterisk (*) identifies to the active channel plan.
To create a new channel plan, tap the [CREATE] soft-key to open the channel plan
creation page. Using you finger, tap on the desired plan template according to
your global region, check the appropriate boxe(s) if either or both analog and
digital channels will be part of this channel plan. The S7200 features an automatic
channel plan builder; it will identify peak levels and frequency of analog carriers
available as well as identify digital carriers. Tap the [Start] soft-key to start
scanning and create the channel plan automatically.
To edit a channel, highlight the desired channel plan first, then use your finger tap
on the desired channel. Press the button to enable or disable the channel
active status.
70
