5.3.8. Disk Management

Disk management function is used to check SATA SSD option or U disk
information. When user's instrument install SATA SSD option, the interface will
display a "Format" button, as the Figure 5-21 shows. If user's instrument no
SATA SSD option, user can not find "Format" button on the screen, as the Figure
5-22 shows. If user's instrument has SATA SSD and U disk at the same time, the
"Format" button only take effect for SATA SSD. If the cursor move on the U disk
postion, the format button will Unavailable.
Figure 5-21 Disk Management – Install SATA SSD Option
Figure 5-22 Disk Management – No SATA SSD Option
