4.1.4. Button introduction

Battery charging indicator light. The indicator light status: The indicator
light status: green means fully charged, red means charging in progress, and red
and green flickering indicates no battery or battery abnormal.
Power on or off the instrument. When user power off the instrument, the
screen will popup a prompting information: Power off or reboot to avoid user
misoperation.
Output feeding current to satellite antenna active indicator light.
DRAIN
Output 22kHz control signal to satellite antenna active indicator light.
22K
ASI input or output active indicator light.
ASI
6 functional shortcut buttons:
: press this button to enter the channel list and channel plan, to create a new
plan, or edit an existing plan.
: press this button to search for a saved file, including saved images, test
results, and auto-test results.
: press this button in any mode to save the screen snapshot or the test results.
: press this button to enter the auto-test function.
: press this button to enter the system setup functions.
: press this button to revert back to the default home screen, no matter which
menu or function you are in.
: If you enter any menu or interface and realize you made a wrong selection,
and wish to return to the previous menu, press
During any operation, if a dialog box pops up for confirmation and it's not what
you wanted, press the
28
S7200 TV Signal Analyzer Operation Manual
button to cancel the operation.
button.
