Modulation Type
Power Level Range
Level Resolution
Power Level Accuracy
MER Measurement
MER Accuracy
CBER/VBER
Constellation
Echo Pattern
DVB-T2 Measurement
Frequency Range
Modulation Type
Power Level Range
Level Resolution
Power Level Accuracy
MER Measurement
MER Accuracy
CBER/LBER
Constellation
Echo Pattern
ISDB-Tb Measurement
Modulation Type
Modulation Bandwidth
Power Level Range
Power Resolution
Power Level Accuracy
310
S7200 TV Signal Analyzer Operation Manual
QPSK, 16 QAM, 64 QAM
-35dBmV ~ +50dBmV
0.1 dB
±1.5 dB (C/N >20 dB)
> 35 dB
±2.0 dB
√
√
√
42~1002MHz
QPSK, 16 QAM, 64 QAM, 256QAM
-35dBmV ~ +50dBmV
0.1dB
±1.5 dB(C/N >20 dB)
>38 dB
±2.0 dB
√
√
√
QPSK, 16 QAM, 64 QAM
6MHz
-35dBmV ~ 50dBmV
0.1dB
±2.0dB (C/N>20dB)
