: Transport stream analysis shortcut key;
l
TV
: Spectrum analysis function shortcut key;
l
: All signals input and output or signals transport path control.
l
④ Input and output signals' indicator.
22K ASI
DRAIN
⑤Main function button
: Channel plan function shortcut key, to enter the channel plan,
l
channel information and editing screens.
: File management shortcut key, to enter the file management
l
function screen.
: File saving function shortcut key, used for saving current
l
measurement result or screen snapshot.
: Auto-test function shortcut key, to enter the auto-test function
l
screen.
: Setup function shortcut key, to enter system parameters setup
l
function screens.
: Home screen shortcut key, to get back to home screen from
l
anywhere.
1 2 3
⑥
ABC DEF GHI
Letter and number key.
⑦
⑧ Enter button
⑨ ESC or return to previous menu or quit one function key
S7200 TV Signal Analyzer Operation Manual
4 5 6 7
JKL MNO PQR STU
arrow keys
8 9 0
- /
VWX YZ*
