Table
Program Association Table (PAT)
Program Map Table (PMT)
Conditional Access Table (CAT)
Master Guide Table (MGT)
Terrestrial Virtual Channel Table (TVCT)
Cable Virtual Channel Table (CVCT)
Rating Region Table (RRT)
Event Information Table (EIT)
Extended Text Table (ETT)
System Time Tables (STT)
In the Virtual Channel Table, which can be present either as Terrestrial Virtual
Channel Table (TVCT) or as Cable Virtual Channel Table (CVCT) depending on the
transmission path, identification information for the virtual channels, i.e.
programs, contained in a multiplexed transport stream are transmitted. The VCT
contains, among other things, the program names. The VCT is thus comparable to
the SDT table in DVB:
In the System Time Table (STT), all the necessary time information is transmitted.
The STT can be recognized by the packet ID = 0x1FFB and the table ID = 0xCD. In
the STT, the GPS (Global Positioning System) time and the time difference
between GPS time and UTC (Universal Time Coordinated (= GMT)) is transmitted.
The Rating Region Table (RRT) can be used for restricting the size of the audience
in terms of age or region. In addition to the information about region (e.g. a
Federal State in the US), information relating to the minimum age set for the
program currently being broadcast is also included. Using the RRT, a type of
204
S7200 TV Signal Analyzer Operation Manual
PID
0x0
per PAT
0x1
0x1FFB
0x1FFB
0x1FFB
0x1FFB
per MGT
per MGT
0x1FFB
Table ID Value (hex)
0x0
0x2
0x1
0xC7
0xC8
0Xc9
0xCA
0xCB
0xCC
0xCD
