5.7. Reviewing & Exporting Files

5.7.1. File management

Tap the button on the front panel below the screen to open the file
management menu. The saved files are available in 3 different categories, picture,
data and TS.
Tap the first soft button multi-times, the button will cycle between [[Picture]],
[[Data]] and [[TS]]. Use your finger tap on the SELECT column to select the desired
file. If no file is chosen, the delete and export buttons are not available. To export
files, insert a USB memory stick in the USB port. The USB icon will appear in the
title bar. Tap the soft button [EXPORT] to export the desired files on the USB stick.
Editable self-created directories will appear on the USB stick, measurement data
files will appear as "ds7200_file" and screen snapshot files will appear as
"ds7200_bmp". Saved TS file can be saved in USB disk root directory. Pressing the
soft button [SORT] will pop up a sorting window offering different sorting choices.
Figure 5-87 File Sorting
When one or more files are selected, the delete button becomes active. When
