Frequency:
Measure BW:
STD:
Modulation:
SR (System Rate):
Standard and Modulation Type
DOCSIS 64QAM
DOCSIS 256QAM
EuroDOCSIS 64QAM
EuroDOCSIS 256QAM
S7200 TV Signal Analyzer Operation Manual
editable content
editable content
DOCSIS、EuroDOCSIS
64QAM、256QAM
The symbol rate is auto-configured according to the
modulation type and standard. It will set automatically
once the modulation type and standard are selected.
Users can input values manually, ranging between
4.00MS/s ~ 7.00MS/s
US and EU Default Symbol Rate for DOCSIS：
Symbol Rate
5.057MS/s
5.361MS/s
6.952MS/s
6.952MS/s
Bandwidth
6MHz
6MHz
8MHz
8MHz
