6.12.11. Record and Replay Transport Stream

Record Transport Stream
S7200 support record transport stream. If user has SATA SSD option, user can
directly record the transport stream on SSD. If user no SATA SSD option, user must
insert USB disk on USB port and record transport stream on USB disk. Open
TV
transport stream record function operation steps: (or TS measurement) ->
[INFO>] -> [RECORD]. When user tap the soft button [RECORD], the screen popup
windows, let use select record device (USB disk or SATA SSD) and saved file name,
as the Figure 6-106 show. If one device not exist, this device status is unavailable
(gray). When the transport stream already started, the record related information
display on the status bar at the bottom of the screen, as the Figure 6-107 show.
Figure 6-106 Start to Record Transport Stream Status
211
