Operating Guide | VLT® AQUA Drive FC 202
1
2
3
4
1 Passive harmonic filter (PHF)
3 Non-fusible disconnect
5 Molded-case circuit breaker (MCCB)
7 dU/dt filter
9 Sine-wave filter
Illustration 6: Visual Representation of a E5h/E6h Enclosure and the Locations of Available Options

3.4 Drive Identification

3.4.1 Identifying the Drive and Its Options

Context:
Enclosure size and specific options are used throughout this guide whenever procedures or components differ based on the drive and
its options. Use the following steps to identify the enclosed drive:
18 | Danfoss A/S © 2018.10
10
6
5
2 Line reactor
4 Fusible disconnect
6 Contactor
8 Common-mode filter
10 Drive module (varies in power rating)
Product Overview
9
8
7
