Operating Guide | VLT® AQUA Drive FC 202

5.3 Wiring Schematic for D9h and D10h Enclosed Drives

3-phase
power
input
+10 V DC
XD2.6
XD2.7
0 V DC - 10 V DC
0/4–20 mA
XD2.8
0 V DC - 10 V DC
0/4–20 mA
XD2.9
XD2.10
XD2.11
XD2.12
XD2.13
XD2.18
XD2.14
XD2.15
XD2.16
XD2.17
XD2.19
Drive
cabinet
1 Terminal 37 (optional) is used for Safe Torque Off. Refer to the VLT
instructions.
Illustration 21: Basic Wiring Schematic for Enclosures D9h and D10h
46 | Danfoss A/S © 2018.10
91 (L1)
92 (L2)
93 (L3)
95 (PE)
10 V DC 24 V DC
50 (+10 V OUT)
+
A53 U-I (S201)
53 (A IN)
ON=0–20 mA
A54 U-I (S202)
OFF=0–10 V
54 (A IN)
55 (COM A IN)
12 (+24 V OUT)
13 (+24 V OUT) P 5-00
24 V (NPN)
18 (D IN)
24 V (NPN)
19 (D IN)
20 (COM D IN)
24 V (NPN)
27 (D IN/OUT)
24 V
0 V
24 V (NPN)
29 (D IN/OUT)
24 V
0 V
24 V (NPN)
32 (D IN)
24 V (NPN)
33 (D IN)
37 (D IN) - option 1)
Switch mode
power supply
15 mA 200 mA
- + -
0 V (PNP)
(COM A OUT) 39
0 V (PNP)
S801/Bus term.
OFF-ON
0 V (PNP)
ON=Terminated
OFF=Open
5 V
0 V (PNP)
S801
(P RS485) 68
RS485
Interface
(N RS485) 69
0 V (PNP)
(COM RS485) 61
0 V (PNP)
®
FC Series - Safe Torque Off Operating Guide for installation
Electrical Installation
(U) 96
(V) 97
(W) 98
(PE) 99
Motor
(R+) 82
Brake resistor
(option)
(R-) 81
Relay1
03
240 V AC, 2A
02
400 V AC, 2A
01
Relay2
06
240 V AC, 2A
05
400 V AC, 2A
04
Analog output
0/4-20 mA
(A OUT) 42
1
Brake temp
(NC)
2
0 V
RS485
2)
(PNP) = Source
(NPN) = Sink
Control compartment
AQ262141056213en-000101 / 130R0882
XD2
Terminal
block
XD2.21
XD2.23
XD2.22
XD2.24
XD2.26
XD2.25
XD2.4
XD2. 5
XD2.2
XD2.3
XD2.1
