Operating Guide | VLT® AQUA Drive FC 202
Table 47: Recommended Fuse Ratings for UL Installation, 525–690 V
Drive model Fuse P/N
N110 Mersen A4J300
N132 Mersen A4J350
N160 Mersen A4J400
N200 Mersen A4J500
N250 Mersen A4J600
N315 Mersen AABY750
N400 Mersen A4BY800
N450 Mersen A4BY1000
N500 Mersen A4BY1000
N560 Mersen A4BY1200
N6300 Mersen A4BY1200
N710 Mersen A4BY1200
N800 Mersen A4BY1200

5.10 Enabling Motor Operation

Context:
If the status line at the bottom of the LCP reads AUTO REMOTE COAST, the unit is ready to operate but is missing an input signal from
terminal XD2.14 in the control compartment. Digital input terminal XD2.14 is designed to receive a 24 V DC external interlock
command that allows the drive to operate when using factory default programming values.
FACTORY-INSTALLED OPTIONAL EQUIPMENT
Do not remove factory-installed wiring to terminal XD2.14. If the drive does not run, refer to the documentation for the
optional equipment that is wired into terminal XD2.14.
Procedure
1. When no interlock device is used, use a push-in type jumper (WAGO 2002-433) between terminal XD2.11 and XD2.14 in the control
compartment. This wire provides an internal 24 V signal on terminal XD2.14. The drive is ready for operation.

5.11 Selecting the Voltage/Current Input Signal

Context:
The analog input terminals XD2.7 and XD2.8 in the control compartment allow setting of input signal to voltage (0–10 V) or current
(0/4–20 mA).
94 | Danfoss A/S © 2018.10
Maximum Cutoff cur-
current [A] rent [A]
175 2400
200 2700
250 3200
350 4600
400 5000
500 8000
600 9000
600 9000
650 11500
750 11500
800 12000
1000 15000
1100 18500
N O T I C E
Peak let thru Maximum
[A] fuse rating F1
[A]
5400 175
6 200
7500 250
10000 350
10400 400
11500 500
12000 600
12000 600
28000 750
28000 750
28000 800
35000 1000
42000 1100
AQ262141056213en-000101 / 130R0882
Electrical Installation
Minimum Class F1
voltage rat-
ing [V]
600 Class L
600 Class L
600 Class L
600 Class L
600 Class L
600 Class L
600 Class L
600 Class L
600 Class L
600 Class L
600 Class L
600 Class L
600 Class L
