Operating Guide | VLT® AQUA Drive FC 202
5.6.2 D10h Wiring Harness
1 DC-link harness to fan supply in output filter cabinet
3 Additional terminal connections
Illustration 24:
Split Shipment Electrical Connections (Input Filter Cabinet + Input Power Options Cabinet + D10h Drive Cabinet)
50 | Danfoss A/S © 2018.10
-XD11.1
-XDL.1
1
-XD4.1
2
2 Cabinet heater supply harness to output filter cabinet
4 Thermal protection wiring harness to output filter cabinet
Electrical Installation
3
4
AQ262141056213en-000101 / 130R0882
